    RV-50C RV Gear Reducer Cyclo Drive Reducer For Industrial Robots ISO9001

    Ask Lasest Price
    Brand Name : Genius Robotics Zhenkang
    Model Number : RV-50C
    Certification : CE , ISO9001 , ISO14001
    Price : Negotiation
    Payment Terms : T/T, L/C
    Supply Ability : 5000 / month
    Delivery Time : 5-10 Working days
    • Product Details
    • Company Profile

    RV-50C RV Gear Reducer Cyclo Drive Reducer For Industrial Robots ISO9001

    RV-50C RV Gear Reducer Cyclo Drive Reducer For Industrial Robots ISO9001



    The rv gear reducer is also known as a cycloidal pinion planetary gear drive, its core components are the pin housing, the crank shaft and the cycloidal wheel.


    The rv reduction gearbox is composed of an involute cylindrical gear planetary reduction mechanism and a cycloidal pinion planetary reduction mechanism. The involute planetary gear is integrated with the crankshaft as an input of the cycloidal pinion transmission part, and the crankshaft drives the cycloidal wheel is eccentrically moved, the crank rotates clockwise in a clockwise direction, and the cycloidal wheel moves one tooth in the counterclockwise direction.

    Industrial robots usually perform repetitive actions to complete the same process; in order to ensure that industrial robots can reliably perform process tasks in production and ensure process quality, the positioning accuracy and repeat positioning accuracy of industrial robots are very high. Therefore, to improve and ensure the accuracy of industrial robots requires the use of RV reducers or harmonic reducers. Another role of precision reducers in industrial robots is to deliver more torque. When the load is large, it is not cost - effective to increase the power of the servo motor. The output torque can be increased by the reducer in a suitable speed range.


    Features of Rv Gear Reducer RV-50C -32.54

    1. Less than 1 arc - min Backlash.
    2. Strong impact resistance.
    3. Very compact with high torsional rigidity.
    4. Component in - line version for greater design and space saving flexibility.
    5. Large transmission ratio range.
    6. High transmission efficiency.
    7. Long working life.


    Application of Rv Gear Reducer RV-50C -32.54

    High - end intelligent equipment industry such as industrial robots, external shafts, precision machine tools, radars, and medical devices.


    Rv Gear Reducer RV-50C -32.54 technical Parameters



    Operating parameter

    Output Rotational speed
    r/min
    5152535
    Output torqueInput capacityOutput torqueInput capacityOutput torqueInput capacityOutput torqueInput capacity
    ModelNmkWNmkWNmkWNmkW
    50C6800.484901.034201.473751.57

    Note: the rated torque is the output torque when the output speed is at 15r/min.


    Performance Parameter

    ModelSpeed ratioAllowable output speedMaximum backlashAllowable acceleration/decleration torqueMomentary max allowable torqueAllowable momentMomentary max allowable movementWeightEfficiencyNoise
    50C

    Reduction gear unit
    Speed ratio value

    r/minarc.minNmNmNmNmkg%dB
    32.54501122524501760350015>80<75



    Rv Gear Reducer RV-50C -32.54 installation parameter


    inner hexagon bolt
    Nominal dimension(mm)
    fastening torque(Nm)fastening forcebolt requirement
    M10 × 1.573.5 ± 3.4338080GB/T 70.1 - 2000
    intensity:12.9
    thread requirement:GB/T 1167-1996


    Rv Gear Reducer RV-50C -32.54 installation drawings


    RV-50C RV Gear Reducer Cyclo Drive Reducer For Industrial Robots ISO9001


    Rv Gear Reducer customers


    RV-50C RV Gear Reducer Cyclo Drive Reducer For Industrial Robots ISO9001
