Shaft Welding Robot Workstation Low-voltage Electrical Shaft, MIG Welding Manipulator

The shaft welding robot workstation is a special equipment specially developed for the shaft welding in the universal circuit breaker in the low - voltage electrical industry. A special rotary - axis welding robot workstation has been introduced.

The shaft welding robot workstation consists of an arc welding robot, a welding power source, a welding gun wire feeding mechanism, a rotary double station positioner, a fixture and a control system. The workstation is used for the welding of various types of workpieces with the rotating shaft as the base body (with several cantilever arms on the top), and various types of shaft automatic welding can be realized by using different clamps in the same workstation. The welding is now highly accurate in position. Due to the use of the double - position positioner, the other parts can be disassembled and assembled while welding, which greatly improves the efficiency.

Technical indicators: shaft diameter: Ф10-50mm, length 300-900mm, welding speed 3-5mm/s, welding process using MAG mixed gas protection welding, positioner rotation, displacement accuracy of 0.05mm.

It is widely used in high - quality, high - precision welding of various types of workpieces for rotating shafts, and is suitable for electric power, electrical, mechanical, automotive and other industries. If manual arc welding is used for shaft welding, the labor intensity of the workers is extremely high, the consistency of the products is poor, and the production efficiency is low, only 2-3 pieces/hour. With the automatic welding station, the output can reach 15-20 pieces / hour, and the welding quality and product consistency are also greatly improved.

MIG welding manipulator body specification

MIG welding manipulator excellent performance

Precision

Unit:mm

Noise

Unit:dB

★ Noted
1. The speed was 100%, the ambient noise was 54.3dB, and the ambient temperature was 15.9°C.
2. Using the pulse sound level meter (HS5660B), the measured value is measured from the distance of 1 m from the measured position.

Welding effect

1. The surface has no rust, no high height, the welding is full and the interface is firm.
2. The welding is consistent and does not need to be polished or reduced by two-thirds.
3. There are no pores, cracks, unfused, slag inclusions, welds, flying rafts, crater cracks, etc. on the surface.

    Shanghai Genius Industrial Co.,Ltd is the branch of Nantong Zhenkang Machinery Co.,Ltd, which founded in 1993, with 30 years of experience in the production of CO2 welding wire feeder, nowadays we occupy 70% Chinese market and 50% global market for wire feeder, long partners of PANASONIC and OTC Daihen.

    In 2009, we started R&D high precison RV reduction gearbox, this is core part of industrial robots, through 4 years research and development, in 2013, our high precision RV reduction gearbox start bulk production. Nowadays we become China biggest RV reduction gearbox manufacturer, realized robotic automatically produce RV reduction gearbox, also we are supplier of world famous company ABB, FNUC, YASKAWA for gearbox.

    As had advantage of wire feeder and RV gear reducer, with accumulated years of welding experience, we decide to R&D welding robot, After more than one year testing, our welding robot developed successfully in 2016, much earlier than other robot manufacturers in China, now our robot already in market for 5 years, still work well, got good comments from customers.
