| Brand Name : | Genius Robotics Zhenkang |
| Model Number : | RV-40E |
| Certification : | CE , ISO9001 , ISO14001 |
| Price : | Negotiation |
| Payment Terms : | T/T, L/C |
| Supply Ability : | 5000 / month |
| Delivery Time : | 5-10 Working days |
High Precision Cycloidal Industrial Robot Arm Joint Speed Gear box Reducer
160E famed provides a widest range of standard and customized solutions for applications in the fields of motion control and mechanical transmission . We supply precision inline planetary gearboxes and right angle planetary gearbox, 90 degree right angle servo motor gearboxes, harmonic drive gearboxes, robot-use RV reducers, grinding precicion rack & gears, servo motor, stepper motor, brushless motor, etc. And our group company also can offer worm gear reducers, gear motors, screw jacks, steering gears, and other related reducer gearboxes and accessories. That means you can get what you want here and will get benefits from our one-stop service that your time and cost will be saved.
Feature
1. Backlash is Less than 1 arc-min
2. Strong impact resistance
3. High Torsional Rigidity
4. Wide range of transmission ratio
5. High Transmission Efficiency
6. Longer working lifespan
RV-20E Working Parameters
Output rotate speed r/min Model | 5 | 15 | 25 | 35 | ||||
Output Torque | Input Power | Output Torque | Input Power | Output Torque | Input Power | Output Torque | Input Power | |
Nm | kW | Nm | kW | Nm | kW | Nm | kW | |
20E | 243 | 0.17 | 180 | 0.38 | 152 | 0.54 | 137 | 0.66 |
Note: The rated torque is the output torque when the output rotate speed is at 15r/min.
RV-20E Performance Parameters
Model | Speed Ratio | Allowable output speed | Maximum Backlash | Allowable acceleration/deceleration torque | Momentary max allowable torque | Allowable moment | Momentary max allowable movement | Weight | Efficiency | Noise | |
Shaft Rotate(R) | Housing Rotate | r/min | arc.min | Nm | Nm | Nm | Nm | kg | % | dB | |
20E | 81 | 80 | 75 | 1 | 450 | 900 | 880 | 1760 | 4.7 | >80 | <75 |
105 | 104 | ||||||||||
121 | 120 | ||||||||||
141 | 140 | ||||||||||
161 | 160 | ||||||||||
RV-20E Installation Parameters
Inner hexagon bolt Nominal dimension x pitch(mm) | Fastening Torque(Nm) | Fastening Force(N) | Bolt Requirement |
M6 ×1.0 | 15.6±0.78 | 13180 | GB/T 70.1-2000 Intensity class:12.9 Thread requirement: GB/T 1167-1996 |
M10×1.5 | 73.5±3.43 | 38080 |
ALL-ROUND PROFESSIONAL TECHNICAL SUPPORT
If you don’t know how to select a suitable gearbox for your machine, please don’t worry. We have a professional technical team to serve you. As long as you follow our steps, you will know how to select the right size. After finishing the selection of matched gearbox for your motor, we will send you the corresponding CAD drawing for your check to avoid any mistakes. We also offer 24 hours technical support if you have any other questions need to solved urgently.
CUSTOMIZED SERVICE IS AVAILABLE
If you need customized gearboxes for unique application, we can offer custom built service according to your requirement. We will provide you with reliable and high performance customized gearboxes in sizes from small to big output torque. Please tell our sale engineer your detailed requirement and all necessary sizes that you want. The more information you provide us, the more suitable customized gearbox we can design for you.
|
|
